MacTac ColorGard 3mil gloss

MacTac ColorGard 3mil Gloss LUV8038 PERMACOLOR ColorGard LUV 8000 Series Laminate

MacTac ColorGard 3mil Gloss LUV8038 PERMACOLOR ColorGard LUV 8000 Series Laminate is a high performance gloss overlaminating film engineered to protect and enhance digitally printed graphics. Designed with a clear permanent acrylic pressure sensitive adhesive and smooth kraft liner, this 3 mil gloss laminate delivers excellent adhesive wet-out, strong clarity, and long term durability.

Built for cold roll lamination, MacTac ColorGard 3mil Gloss LUV8038 supports UV, latex, solvent, eco-solvent, and UVgel printed graphics in both indoor and outdoor environments.

---

Why Choose MacTac ColorGard 3mil Gloss LUV8038

MacTac ColorGard 3mil Gloss LUV8038 provides premium image protection with consistent production performance.

• 3 Mil Gloss PVC Film: Enhances color vibrancy and depth with a uniform high gloss finish.
• Excellent Adhesive Wet-Out: Minimizes silvering and maintains image integrity.
• Permanent Acrylic Adhesive: Delivers dependable long term bonding.
• UV Inhibitors Built In: Helps slow color fade from ultraviolet exposure.
• Up to 5 Years Outdoor Durability: Supports long term exterior graphics.
• Cold Roll Lamination: Processes between 40°F and 104°F without heat.

---

Applications

• General purpose laminate for digital prints
• Murals and exhibits
• Retail posters and displays
• Event graphics
• Photographic prints
• UV inkjet and screen printed graphics
• Latex, solvent, eco-solvent, and UVgel prints

---

Key Features

• Film Type: Clear vinyl (PVC)
• Finish: Gloss
• Thickness: 3.0 mil film, 3.8 to 4.3 mil total with adhesive
• Adhesive Type: Clear permanent acrylic pressure sensitive
• Liner: 50# to 58# white kraft liner
• Length: 150 feet
• Outdoor Durability: Up to 5 years
• Application Temperature: 40°F to 104°F
• End Use Temperature: -20°F to 140°F
• Adhesive pH: Neutral

---

Specifications

Thickness (Film plus Adhesive):

• Approximately 0.0038 to 0.0043 inches

Peel Adhesion on Glass:

• 20 minutes: 4.34 lb/in
• 24 hours: 5.0 lb/in

Quick Tack on Stainless Steel:

• 3.0 lb/in²

Shear Strength:

• 150 hours to fail at 2.2 lbs @ 72°F

Flame Spread:

• Class A rating

---

Print Compatibility

MacTac ColorGard 3mil Gloss LUV8038 supports:

• UV cure inkjet
• Eco-solvent
• True solvent
• Latex
• Canon UVgel (1640 and 1650)
• Water-based inkjet prints

LUV laminates are engineered to wet out immediately over UV inkjet prints.

---

Durability

• Outdoor: Up to 5 years
• Indoor: Extended service life beyond outdoor rating

Overall graphic longevity depends on ink quality, environmental exposure, and base media selection.

---

Chemical Resistance

Resists short term exposure to water, detergents, alcohol, and some aliphatic solvents. Avoid contact with ketones, esters, aromatic solvents, and chlorinated hydrocarbons.

Seal edges when exposure to moisture, chemicals, or high pressure wash is expected.

---

FAQ

What makes LUV8038 different from standard laminates?
It delivers superior adhesive wet-out, UV resistance, and long term gloss protection for digitally printed graphics.

Can it be used with UVgel prints?
Yes. It supports Canon UVgel systems and wets out quickly over UV inkjet prints.

Is it suitable for outdoor murals?
Yes. It supports up to 5 years outdoor durability when properly applied.

Does it require heat during lamination?
No. Use cold roll lamination only.

---

Protect and Enhance Your Printed Graphics

Choose MacTac ColorGard 3mil Gloss LUV8038 for high gloss protection and dependable long term performance across digital print applications.
