MacTac Optical P/R Acrylic Mounting Adhesive
Price: Select an Option
MacTac Optical P/R Acrylic Mounting Adhesive CT2200
MacTac Optical P/R Acrylic Mounting Adhesive CT2200 is a 2 mil optically clear permanent and removable mounting film engineered for precision face and second surface applications. Designed with permanent adhesive on one side and removable adhesive on the other, this clear mounting film delivers exceptional clarity for glass and acrylic graphics while maintaining controlled removability.
As part of the Permacolor system, CT2200 enables fast, efficient cold roll lamination without heat, drying time, or messy liquid adhesives, making it ideal for production environments focused on clean presentation and reliable performance.
Why Choose MacTac Optical P/R Acrylic Mounting Adhesive CT2200
This optically clear mounting film is built for high visibility applications where clarity and removability both matter.
- Dual Adhesive System: Permanent clear acrylic on one side for secure bonding and removable clear acrylic on the other for clean removal up to 6 months.
- Optically Clear Construction: Superior transparency for face mounting and second surface window graphics.
- Polyester Carrier: Stable 2 mil clear film resists distortion and maintains smooth presentation.
- Cold Roll Application: Processes between 50°F and 120°F without heat.
- UV Protection: Helps reduce fading caused by ultraviolet light exposure.
- Vinyl and Phthalate Free: 100% chlorine, vinyl, and phthalate free construction.
- Non-Water Whitening: Maintains clarity during wet applications.
Applications
- Face mounting graphic images to glass
- Second surface window graphics
- Removable indoor window signage
- Outdoor window signage
- POP displays
- Cabinet light boxes
- Flat and slightly curved transparent surfaces
Key Features
- Film Type: Optically clear polyester
- Thickness: 2 mil carrier, 3.7 mil carrier plus adhesive, 6.7 mil total product
- Adhesive Type: Clear acrylic pressure sensitive, permanent on one side, removable on the other
- Release Liner: Clear polyester liner on both sides
- Removability: Up to 6 months from glass, Plexiglas, and acrylic sheeting
- Application Temperature: 50°F to 120°F
- End Use Temperature: -40°F to 185°F
- Shelf Life: 2 years at 75°F and 50% relative humidity
Specifications
Thickness:
- Carrier plus adhesive: 0.0037 inches
- Total product: 0.0067 inches
Quick Tack on Stainless Steel:
- Permanent side: 2.8 lb/in²
- Removable side: 2.5 lb/in²
Peel Strength on Stainless Steel:
- 30 minutes: Permanent 4.0 lb/in | Removable 1.2 lb/in
- 24 hours: Permanent 5.2 lb/in | Removable 1.6 lb/in
Shear Strength:
- Permanent: 100+ hours
- Removable: 24+ hours
Performance & Handling
- Designed for cold roll lamination only
- Use wet application technique for field glass installs
- Seal edges when exposed to moisture, chemicals, or high pressure wash
- Condition polycarbonate or acrylic panels prior to mounting to reduce outgassing
- Handle rolls carefully to prevent wrinkles, adhesive distortion, or liner tunneling
Removability Notes
CT2200 removes cleanly up to 6 months after application from glass, Plexiglas, and acrylic surfaces. Adhesion may increase over time on polystyrene, nitrocellulose painted surfaces, or soft PVC, which may result in adhesive residue.
Always test for substrate compatibility before full production.
FAQ
Is this product fully clear with no haze?
Yes. CT2200 is optically clear and designed for high visibility face mounting applications where clarity is critical.
Which side is removable?
The removable adhesive side is wound out for easier application and controlled removal.
Can it be used outdoors?
Yes. It performs in indoor and outdoor applications with an end use temperature range from -40°F to 185°F.
Is it suitable for backlit graphics?
Yes. It was designed primarily for mounting photographic transparencies and backlit applications where superior clarity is required.
Achieve Clear, Professional Mounting Results
Select an MacTac optically clear mounting film that delivers secure adhesion, clean removability, and premium presentation for window and transparent graphic applications.
