General Formulations 830 AutoMark High-Gloss White Cast Wrap Vinyl with DRIFT – Removable Repositionable

GF 830 AutoMark 2.0 MIL GLOSS WHITE WRAP VINYL

GF 830 AutoMark™ Cast with DRIFT® Technology is engineered for professional installers who need high-performance wrap vinyl for demanding applications. Designed specifically for vehicle wraps, fleet graphics, and complex surfaces, this premium 2.0 mil cast film combines slideable positioning with air-egress technology for faster, cleaner installations.

The repositionable grey adhesive system helps prevent substrate show-through while allowing installers to reposition graphics during application. Once pressure is applied, the adhesive activates for a secure bond.

With excellent conformability for rivets, deep channels, and complex curves, GF 830 is a strong choice for wraps that require durability, visual impact, and long-term outdoor performance.

Applications

• Vehicle wraps
• Fleet graphics
• Commercial vehicle branding
• POP and retail signage
• Window graphics
• Outdoor signage
• Indoor graphics
• Flat and curved surface graphics
• Die-cut decals
• OEM painted metal applications

---

Key Features

• Film Construction: 2.0 mil premium gloss white cast vinyl
• Adhesive Technology: DRIFT® slideable repositionable grey adhesive
• Air Egress: Bubble-free installation performance
• Conformability: Excellent for rivets, deep channels, and complex curves
• Opacity: 99% opacity for strong color blocking
• Durability: Up to 8 years outdoor durability
• Removability: Clean removability up to 4 years under proper conditions
• Print Compatibility: Compatible with solvent, eco-solvent, latex, UV curable, screen, and UV offset inks
• Installation: Dry apply recommended
• Finish: High-gloss appearance for vibrant graphics

---

Technical Specifications

Film

• Film Type: Cast white vinyl
• Thickness: 2.0 mil
• Gloss Level: >90 gloss units
• Opacity: 99%
• Elongation: MD >200%
• Dimensional Stability: MD <0.35 mm

Adhesive

• Type: Solvent acrylic
• Adhesive Thickness: 1.2–1.4 mil
• 15 Minute Peel Strength: 2.5 lbs/in
• 24 Hour Peel Strength: 3.0 lbs/in

Performance

• Application Temperature: Above 50°F
• Service Temperature: -40°F to 180°F
• Outdoor Durability: Up to 8 years
• Shelf Life: 2 years
• Storage Conditions: 70°F / 50% RH

---

Recommended Laminates

GF 830 pairs with several General Formulations cast laminates for long-term wrap protection and finish customization:

Matching Laminates

• GF 813 AutoMark™ High Gloss Clear UV Cast Laminate
• GF 831 AutoMark™ Gloss Clear UV Cast Laminate
• GF 840 AutoMark™ Matte Clear UV Cast Laminate
• GF 844 AutoMark™ Ulti-Matte Clear UV Cast Laminate

Additional Laminates

• GF 242 OptiMark™ Gloss Optically Clear UV Cast Laminate
• GF 108 Satin Anti-Graffiti Laminate (flat applications only)

---

FAQ

What is GF 830 AutoMark™ designed for?

GF 830 delivers high-performance results for vehicle wraps, fleet graphics, commercial branding, and other long-term applications that require excellent conformability over curves, rivets, and recessed surfaces.

What does DRIFT® Technology do?

DRIFT® Technology lets installers slide and reposition the film easily during application for precise alignment. The built-in air-egress channels push out trapped air and help create a smooth, bubble-free finish.

Is GF 830 good for full vehicle wraps?

Yes. GF 830 handles full vehicle wraps with confidence, including complex curves, deep channels, rivets, and fleet graphics.

What printers are compatible with GF 830?

GF 830 works with solvent, eco-solvent, latex, UV curable, screen, and UV offset printing technologies.

Can GF 830 be repositioned during installation?

Yes. The slideable adhesive system lets installers reposition the vinyl during application. Once the installer applies squeegee pressure, the adhesive locks the graphic into place.

Does GF 830 have air-release technology?

Yes. The liner uses slideable air-egress technology to help installers eliminate trapped air and reduce bubbles during installation.

How long does GF 830 last outdoors?

GF 830 delivers up to 8 years of outdoor durability under vertical exposure conditions.

Is the adhesive removable?

Yes. GF 830 removes cleanly for up to 4 years in many applications. Installers may need heat during removal, and certain surfaces or environmental conditions may cause some adhesive transfer.

What laminate should I use with GF 830?

Pair GF 830 with GF 813, GF 831, GF 840, or GF 844 cast laminates to match the finish, durability, and protection level your application requires.

---

Build Better Wraps with GF 830 AutoMark™

Get professional wrap performance, smoother installations, and long-term durability with General Formulations GF 830 AutoMark™ Cast Wrap Vinyl. Contact Big Systems to find the right laminate and print solution for your next wrap project.

Flammability (tested using GF 830 laminated with GF 831, GF 840); ASTM E84 Class 1 or A (Rating Standard Test Method for Surface Burning Characteristics of Building Materials).
